Loader 63 - Automatic Loading System - Patented

- 4 lifting arms with suction cups
- Min. panel dimensions: Height - 1.000 mm to 2.100 mm
- Max. panel dimensions: Lenght - 2.500 mm to 12.000 mm

Standard Equipment

- PLC management for arms to be used, cycle and activation for detaching unit - Error codes on the CNC panel router PLC
- Anti-intrusion safety light barriers
- Panel pallet swap without CNC panel router cycle interruption
- Max. panel stacking height on pallet (from ground) 520 mm (15’’)
- Max. lift weight kg 25 (55 lb) on every arm, at 7 bar (102 psi) pressure
- Sensor detector informing when panel stacking is running out
- Automatic vacuum cups activation by panel measure
- PLC controlling the sequence of lifting and positioning of the panel from 0° ± 105° - CE Certification
- Pneumatic System (CE norm compliant) with filter/pressure regulator with outflow of condensation. It can be locked and it has a digital indication of pressure
